Copying, pasting, and moving cells are simple everyday tasks for Excel users. But what if something already occupies the area we want to paste to? We must perform the move-move-move shuffle by moving something into a temporary location before placing everything into its final destination. Wouldn’t it be better if there were a simple way to swap ranges in Excel? Wouldn’t it be better to just select the ranges and click one button? Yes, it would, and that is what we are covering in this post.
Table of Contents
Download the example file: Click the button below to join the Insiders program and gain access to the example file used for this post.
File name: 0180 VBA swap ranges.xlsm
Watch the video
When to swap ranges
Here is a scenario I’m sure you can identify with. You’ve received a workbook that is used within a presentation. However, you (or your manager) want to present the items in a different order.
You could start with the move-move-move shuffle. Alternatively, if the following VBA code is available in your Personal Macro Workbook, you can simply select the ranges and run the macro.
Paste the code below into a standard code module of your Personal Macro Workbook.
To make the code more reusable, add a button to your ribbon or quick access toolbar; then it’s just one click away. 👍
Sub SwapSelectedRanges() 'Set up the macro Application.DisplayAlerts = False Application.ScreenUpdating = False 'Create variables to hold the ranges Dim rng As Range Dim temp1Ws As Worksheet Dim temp2Ws As Worksheet Dim temp1Rng As Range Dim temp2Rng As Range 'Get the selected ranges Set rng = Selection 'There must be two areas selected If rng.Areas.Count <> 2 Then MsgBox "Please select two ranges." GoTo CleanUp End If 'All areas must be the same size If rng.Areas(1).Rows.Count <> rng.Areas(2).Rows.Count Or _ rng.Areas(1).Columns.Count <> rng.Areas(2).Columns.Count Then MsgBox "All ranges must have the same number of rows and columns." GoTo CleanUp End If 'Check that ranges don't intersect with each other If Not Intersect(rng.Areas(1), rng.Areas(2)) Is Nothing Then MsgBox "Selected areas must not overlap." GoTo CleanUp End If 'Create temporary sheet for moving values On Error Resume Next Set temp1Ws = ThisWorkbook.Sheets.Add Set temp2Ws = ThisWorkbook.Sheets.Add If Err.Number <> 0 Then MsgBox "Unable to create a temporaray worksheet for moving cells." GoTo CleanUp End If On Error GoTo 0 'Create a temporary range Set temp1Rng = temp1Ws.Range("A1").Resize(rng.Areas(1).Rows.Count, rng.Areas(1).Columns.Count) Set temp2Rng = temp2Ws.Range("A1").Resize(rng.Areas(2).Rows.Count, rng.Areas(2).Columns.Count) 'Perform the swap On Error Resume Next rng.Areas(1).Copy Destination:=temp1Rng rng.Areas(2).Copy Destination:=temp2Rng temp1Rng.Copy rng.Areas(2).PasteSpecial Paste:=xlPasteAll temp2Rng.Copy rng.Areas(1).PasteSpecial Paste:=xlPasteAll If Err.Number <> 0 Then 'Error occured, so restore previous ranges and clean up temp1Rng.Copy Destination:=rng.Areas(1) temp2Rng.Copy Destination:=rng.Areas(2) MsgBox "Unable to swap the selected ranges" GoTo CleanUp End If 'Clean up and reset CleanUp: On Error Resume Next temp1Ws.Delete temp2Ws.Delete On Error GoTo 0 Application.DisplayAlerts = True Application.ScreenUpdating = True rng.Select End Sub
Using the VBA code
The macro is simple to use:
- Select the first range
- Hold Ctrl, select the second range
- Run the macro
Done! That’s it – how easy was that!
When using the macro, there are a few things to be aware of:
- The code requires two separate ranges to be selected.
- The two ranges must be the same size (i.e., containing the same number of rows and columns).
- The range swap includes any hidden columns or rows
- Formatting is also swapped as part of the range
- The workbook containing the macro must be unlocked to create a temporary location on a new worksheet.
- The code only works on ranges that exist in the same worksheet
Adapting the code to your needs
What if you don’t want to swap everything in the range? For example, you may want to swap values but not formats.
It is simple to change the macro above for more scenarios.
Change the xlPasteAll code for one of the following:
- xlPasteFormulasAndNumberFormats: Swap values and formulas, keeping the number formatting but not other cell formatting.
- xlPasteValuesAndNumberFormats: Swap values and hard code formulas, keeping the number formatting but not other cell formatting.
- xlPasteFormats: Swap the cell formats only; the values and formulas do not move.
- xlPasteFormulas: Swap values and formula only, formatting does not move.
- xlPasetValues: Swap values and hard code formulas, formatting does not move.
A list of other types can be found here: https://learn.microsoft.com/en-us/office/vba/api/excel.xlpastetype
Rather than using the move-move-move shuffle, add the VBA macro in this post to your Personal Macro Workbook to easily swap ranges in Excel with 1-click.
